| 브랜드 이름: | ZXY |
| 모델 번호: | ZXY-PQ |
| MOQ: | 협상 가능 |
| 가격: | 협상 가능 |
| 포장에 대한 세부 사항: | 판지 상자 |
| Feature | Performance Characteristic | Technical Benefit |
|---|---|---|
| Core Material | Low-loss Mn-Zn ferrite material | Reduces core loss at high frequencies, improving overall energy efficiency |
| Frequency Range | 20 kHz to 200 kHz (customizable) | Enables high-frequency operation, reducing transformer size and weight |
| Power Density | Compact PQ core geometry | Optimizes space utilization within the charging module |
| Operating Temperature | Class B / Class H insulation system (130°C - 180°C) | Ensures reliable performance under continuous full-load operation |
| Dielectric Strength | High isolation voltage (typically 3000VAC - 4000VAC) | Provides robust electrical safety isolation between primary and secondary |
| Winding Technology | Precision multi-strand Litz wire or copper foil | Minimizes skin effect and proximity effect losses at high frequencies |
| Efficiency | Up to 98% (depending on design parameters) | Reduces energy waste and lowers cooling requirements |
| Leakage Inductance | Controlled low leakage inductance | Essential for soft-switching topologies (e.g., LLC resonant converters) |
| Thermal Management | Optimized winding layout and core design | Ensures even heat distribution, enhancing long-term reliability |
| Customizability | Turns ratio, inductance, and mounting style adjustable | Adaptable to various power levels (20kW - 240kW+) and circuit topologies |
|
|
