| 브랜드 이름: | ZXY |
| 모델 번호: | ZXY-G14 |
| MOQ: | 협상 가능 |
| 가격: | 협상 가능 |
| 포장에 대한 세부 사항: | 판지 상자 |
| Feature | Description |
|---|---|
| Impedance Ratio | 600Ω : 600Ω (1:1) - Provides precise impedance matching between microphones, preamps, and mixers for optimal signal transfer |
| Frequency Response | 20Hz - 20kHz (±0.5dB typical) - Delivers flat, wide-bandwidth performance across the full audible spectrum |
| Distortion | Low THD (< 0.1% @ 1kHz, typical) - Maintains signal purity with minimal harmonic distortion |
| Insertion Loss | < 0.5dB - Ensures efficient signal transmission with negligible level loss |
| Isolation Type | Galvanic isolation - Physically separates input and output to eliminate ground loops and block DC voltage |
| Noise Rejection | High common-mode rejection - Effectively suppresses EMI, RFI, and hum (50Hz/60Hz) for clean audio |
| Core Material | High-permeability nickel-alloy or premium magnetic core - Provides low distortion, high linearity, and wide frequency response |
| Shielding | Encapsulated or mu-metal shielding (as applicable) - Reduces external electromagnetic interference for stable operation |
| Dielectric Strength | > 500V (input to output) - Offers reliable electrical isolation and equipment protection |
| Operating Temperature | -20°C to +85°C - Suitable for studio, broadcast, and live sound environments |
| Mounting Type | PCB pin / solder lug - Compact footprint for easy integration into existing or DIY audio equipment |
| Application | Microphone input, tube preamps, DI boxes, mixing consoles, broadcast consoles, recording interfaces, and vintage gear restoration |
|
